MiniProf BT Wheel is a high precision, lightweight and portable tool for performing fast and reliable cross-sectional wheel profile measurements to monitor and analyze the wear of wheels. It is equipped with Bluetooth®, has an option for cable connection and comes in few variations depending on your requirements. Magnetically attached to the backside of the wheel, the wheel profile is measured in less than 5 seconds and a complete railroad car in less than five minutes.
Get instant results
Wear parameters such as Sd, Sh and qR values are displayed instantly after each measurement in real time view. Numerous additional calculations and alignments are included in the powerful Envision software for basic to advanced data handling, analyzing and reporting
Wheel analysis & calculations
The MiniProf Envision software visualises and calculates residuals and areas automatically.
Measurements can be compared in multiple ways and are easily exported to various formats.
Reprofiling
The MiniProf BT Wheel system is ideal to use before and after reprofiling of the wheels to determine when to reprofile and how much material to take off during the reprofiling process. This leads to precise reprofiling and improved lifetime of the rolling stock due to the unmatched high accuracy of the MiniProf system.
Fast measuring with schemes
When measuring multiple profiles, the MiniProf BT measuring scheme is a very strong tool for clear identification of each profile in advance and for simplifying and reducing the measuring process even further.
Profile measurements – from tram vehicles to locomotives
MiniProf Wheel Mini is the smallest member of the MiniProf Wheel family. With its compact and lightweight design, it is a versatile tool for measuring most types of wheels from compact tram wheels to locomotive wheels.
With only a small 100 mm backplate, it fits right in the palm of your hand and can be used even if only limited measuring space is available. It is fast and easy to operate and provides the same excellent profile accuracy and reliability as always.
Profile and back-to-back in a single measurement
The MiniProf Wheel Back-to-Back system measures both the wheel profile and back-to-back distance of the wheelset in a single, quick measurement. Magnetically attached between the backsides of the wheels and connected by a solid rod, it can be applied directly under rolling stock or on standalone wheelsets.
Combined profile and diameter measurement
The MiniProf Wheel 400 is equipped with a wide 400 mm backplate, enabling both wheel profile and diameter readings in a single measurement.
The wide spacing between the flange contact points provides a large reference span across the wheel, making the MiniProf Wheel 400 ideal for applications where both profile shape and diameter need to be documented simultaneously.
As with similar tools, the diameter is calculated using the commonly applied versine measuring principle, which assumes an ideal wheel shape without local deformations. This should always be considered when interpreting diameter results.
Specifications
| | |
|
|---|---|---|---|
| Product ID | MP-160 | MP-165 | MP-163 / MP-164 |
| Profile accuracy | Better than: ± 9 µm Repeatability: ± 2.5 µm | Better than: ± 9 µm Repeatability: ± 2.5 µm | Better than: ± 9 µm Repeatability: ± 2.5 µm |
| Back-to-back accuracy | - | 200 µm | - |
| Diameter accuracy * | - | - | 800 mm wheel: 30 µm 1000 mm wheel: 50 µm 1200 mm wheel: 80 µm |
| Measuring speed | Less than 5 seconds | Less than 5 seconds | Less than 5 seconds |
| MiniProf Envision - Measurement - Analysis | Supported Supported | Supported Supported | Supported Supported |
| MiniProf Criterion - Measurement - Analysis
| Supported Supported for select calculations | Supported Supported for select calculations | Supported Supported for select calculations |
| Weight | 0.7 kg | 2.0 kg | 1.4 kg |
| Operating temperature | -15˚C to +50˚C | -15˚C to +50˚C | -15˚C to +50˚C |
* According to the Versine measuring principle.
Scope of delivery
A MiniProf Wheel system is delivered with access to the MiniProf Criterion mobile app for iOS and Android, the full Envision software package, Bluetooth® and cable connection, video tutorial guides, software support, and a customised, lightweight, and rugged transport case with room for the measuring system and accessories for safe storage and transportation.
Trade in your old MiniProf or approved laser-based instrument and unlock the latest in digital profile measurement and advanced data processing – now with an extended 10-year warranty option
