MiniProf BT Rail is a high precision, lightweight and portable tool for performing fast and reliable cross-sectional rail profile measurements to monitor and analyze the wear of rails. It is equipped with Bluetooth®, has an option for cable connection and is available for all type of rails, including grooved rails. Magnetically attached to the top of the railhead, the rail profile and track gauge is measured in one single measurement in less than 5 seconds.

Watch the MiniProf Rail video

获得即时结果

每次测量完毕,垂直方向、水平方向和一定角度的钢轨磨耗立即在实时窗口显示。Envision软件还包含大量的计算功能和校核功能,用于从基本到深入的数据操作、分析报告等。

钢轨分析&计算功能

MiniProf Envision软件能查看和自动计算剩余量和剩余面积,以及用于钢轨打磨分析的特殊功能。测量文件能够通过多种不同的方法进行比较,并轻松地输出到各种格式。

GPS位置

MiniProf Envision软件能记录每次测量时的GPS位置信息,并可将现场照片附加到特定测量文件。这个功能十分有益,可定位和标记轨道线路上的具体测量点。

快速测量方案

MiniProf Envision软件含有一个测量方案系统,适用于大量车轮、钢轨或制动盘剖面序列的测量。通过智能方案导引功能,用户能够配置特定解决方案,满足个性化要求,轻松、快速、高效地测量。

轨距测量

MiniProf蓝牙钢轨外形测量仪带有伸缩杆,使用测量点相对一侧钢轨上作为基准点,确保设备放置正确稳定并防止倾斜。根据系统配置,单一测量完成后可立即同时显示轨距值和钢轨廓形。

超高和角度

根据系统配置,设备配置有偏转传感器,自动测量超高和角度。采集数值存储在测量文件中,能够在任意时间显示。偏转角度的测定范围是±30°。

技术规格

产品型号MP-260-IPMP-261-IPMP-262-IP
配置垂直正交定位装置轨距测定
角度
超高
(适用于槽型轨)
轨距测定
角度
超高
垂直正交定位装置
剖面精度优于:± 11 µm
重复性:± 2.5 µm
优于:± 11 µm
重复性:± 2.5 µm
优于:± 11 µm
重复性:± 2.5 µm
测量速度小于5秒小于5秒小于5秒
MiniProf Envision软件
- Measurement
- Analysis

Supported
Supported

Supported
Supported

Supported
Supported
MiniProf Criterion软件
- Measurement
- Analysis


For details, see the Criterion Compatibility Chart


Supported
Supported for select calculations

Supported
Supported for select calculations

Supported
Supported for select calculations
重量0.8 kg0.7 kg1.2 kg
工作温度-15˚C至+50˚C-15˚C至+50˚C-15˚C至+50˚C
IP ratingIPX4IPX4IPX4

供货范围

MiniProf钢轨系统供货时,包括安卓系统MiniProf Criterion应用、完备的Envision软件包,蓝牙连接和数据线连接,培训视频、软件支持和坚固、轻量的特制运输箱。设备箱内有测量系统、附件等内置空间,可安全存储和运输。伸缩杆用于连接到另一侧的钢轨,放置在特制的杆包中另行交付。
